Smiths Interconnect Rectangular Connectors

Smiths Interconnect offer a broad range of modular and rectangular connectors. Their modular solutions allow the user to customize, configure and combine signal, power, coax, twinax, triax, quadrax, filter and fibre optic contacts into a single connector.

Smiths Rectangular Connectors

B Series Connectors:

  • Up to 100 signal 1.50mm contacts and 500 mating cycles.
  • Interchangeable contact retaining system.
  • Bilevel contact modules (BC, BGD).
  • In compliance with NF F61-030, NF F16-101, NF F16-102.

Fibre Channel D-Sub Connectors:

  • Standard keyed and non-keyed insert arrangements: 2, 4, 6, 8 way; hybrid options available.
  • Offered with 150 Ohm impedance Data rates up to 6.25 Gbps.
  • Six-position keyed and non-keyed jack post versions.
  • Common back shells with a wide assortment of accessories, guide hardware and sealing grommets.
  • Integrated EMI spring fingers offer superior EMI performance with low contact resistance.

Filter Combo D-Sub Connectors:

  • MIL-DTL-24308, MIL-DTL-83513 Micro-D and Combo D-Sub style connectors.
  • EMI/RFI filtering and transient protection. Aluminium shell.
  • Intermateable and Interchangeable with standard non-filter connectors.
  • Exceed all applicable requirements of defence specifications.
  • PC tail, solder cup, and solderless press-fit terminations.

Filtered Rack & Panel Connectors:

  • Meets or exceeds all applicable requirements of military specifications.
  • Offered in a number of different contact arrangements and shell sizes.
  • C, L, Pi filter types Filtering technology (Planar Arrays, Discoidal) to suit application.
  • Unfiltered (high speed) and ground lines.
  • Transient Protection to RTCA D160F Section 22 levels 3,4 & 5.
  • Protection against primary lightning, EMI and EMP.

H Series Connectors:

  • High density, with up to 1000 signal 0.60mm contacts.
  • Modularity: can mixed signal, power and coaxial contacts.
  • Metallic shell with cable clamp from 12mm to 25mm.
  • 5000 mating cycles with threaded jackscrew, 15000 with 1/2 turn jackscrew.
High Speed Arinc 600 Connectors
PDF Speed Arinc Datasheet

High Speed Arinc 600 Connectors:

  • Bandwidth: Up to 3 Gigahertz Low-latency, high-throughput signal processing applications.
  • Data rates exceeding 2 Gbit/Sec supported, with Low skew & jitter.
  • Matched impedance differential contact pairs.
  • Differential Twinax & Quadrax support.
  • Standard & Custom Insert Arrangements.
  • Anti-Rotational Cavities.

High Speed MIL-DTL-83527 Connectors:

  • Isolated cavities available for tempest applications.
  • Contact patterns include mixed Signal, Power, Coax, Triax, fibre Optic (ARINC 801 and Expanded Beam Contacts) Twinax and Quadrax contacts for standard or custom insert arrangements.
  • EMI/RFI environmentally sealed back-shells.
  • Single or Multiport exit termination points with standard MIL-DTL-38999 back-shells.

HyperMod Series Connectors:

  • Modularity mixed signal, power, coaxial, high speed and fibre optics contacts.
  • IP67 rugged aluminum shell.
  • Several housing & hoods, single or double locking systems.
  • Conforms to DIN 43652 standards and NF F61-030 railways approved.
  • High shock and vibration proof: EMI & RFI protection.

L Series Connectors:

  • Mixed signal, power, and coaxial modules. Provides up to 200 amps power.
  • Cable to chassis and rack & panel; Plastic backshell with strain relief and half turn quick disconnect jackscrew.
  • Float mountable for blind mating.
  • Configurations compliant to EN45545 standards Different signals.
  • High reliability contact technology.
  • Several locking devices and hood are available.

LHS/LHZ Series Connectors:

  • Flat floating connector, ideal for blind mating.
  • Mixed power, signal, coaxial and quadrax contacts.
  • Rack/panel applications (norm XPF61-005).
  • Compliant with NF F 61-032 standards.
  • High contact density, up to 70 signal contacts.

MDCX Series Connectors:

  • MDCX VSWR of 1.25:1 (typ) up to 10 GHz (max mated pair).
  • Maximum overall diameter of 0.125" fitted into low-profile Micro-D housing.
  • Constant 50 Ohm airline impedance.

MDHC Series Connectors:

  • MDHC VSWR of 1.5:1 (typ) up to 40GHz (max mated pair).
  • Maximum overall diameter of 0.125" fitted into low-profile Micro-D housing.
  • Constant 50 Ohm airline impedance.

Micro-D Filter Series Connectors:

  • MMIL-DTL-24308, MIL-DTL-83513 Micro-D and Combo D-Sub style connectors.
  • EMI/RFI filtering and transient protection.
  • Inter-mateable and Interchangeable with standard non-filter connectors.
  • Exceed all applicable requirements of defence specifications.
  • PC tail, solder cup, and solderless press-fit terminations.
MIL-DTL-24308 (D-Sub) Connectors

MIL-DTL-24308 (D-Sub) Connectors:

  • MIL-DTL-24308 D Sub-miniature filter connectors.
  • Inter-mateable and interchangeable with the standard non-filtered connectors.
  • Combo D-Sub arrangements for power coaxial and signal contacts mixed arrangements.
  • Layouts include 5W5, 8W8, 17W2, 9W1 and 24W7.

N Series Connectors:

  • VITA 66.1 multichannel motherboard / daughter card connectors for ruggedized optical backplane Interconnects.
  • Provides a high-density, blind-mate optical interconnect in a backplane/daughtercard configuration.
  • Up to two MT ferrules per connector, each accommodating up to 24 fibre paths.

REP Series Connectors

Environmentally-Sealed Rectangular Plastic Connectors

Optimised for use in rail and embedded applications.

  • Suitable for a wide range of applications inc. industrial, rail, test and measurement, automotive, public works and defence.
  • Original REP connector available with the proven Hypertac® hyperboloid contact technology which allows up to 20,000 mating cycles.
  • ‘NEW’ EasyREP version using MR screw machined contacts allowing up to 500 mating cycles.
  • REP and EasyREP connectors available in three layouts, with 2, 6, and 12 ways.
  • Crimp, straight or bent termination options.
  • Smart design with integrated functions.
  • Shunts available as required.

Rugged D-Sub with Twinax/Quadrax & Split Pair Quadrax:

  • Low RF noise and high durability over 500 mating cycles.
  • Offered with 100 ohm quadrax and/or differential pair twinax contacts.
  • Higher bandwidth with split pair quadrax contacts, support up to 10 Gbps.
  • Optimized impedance matching for signal integrity.
  • Size 10 contacts are 30% smaller package size for tight space constraints.
  • Cable assembly options available.

Transformer Series Connectors:

  • High density modular solution.
  • High power, up to 300A / 500A.
  • Straight, angled and shunt termination styles.
  • Cable section size from 25mm² to 50mm² / 240mm².
