Amokabel Marine
Amokabel’s innovative TEXILine Heli Twist series is an eco-friendly shipboard power cable solution designed to reduce weight, improve installation efficiency, and optimise electrical performance.
Featuring a helically twisted design, these cables minimise conductor cross-section by up to 30% compared to traditional shipboard cables, ensuring superior heat transfer and resistance to electro-mechanical forces during short circuits. With a focus on sustainability and profitability, the TEXILine Heli Twist range is ideal for marine and offshore environments.
TEXILine Heli Twist Cu:
- DNV-approved 1kV cable for fixed installations indoors and outdoors
- Flexible copper conductors (IEC 60228 class 5) for easy installation
- Helically twisted design ensures effective heat transfer and high current capacity
- XLPE insulation for reliability in narrow spaces and harsh marine conditions
TEXILine Heli Twist Cu EMC:
- Similar to Cu variant, with an added braided copper screen for electromagnetic compatibility (EMC)
- High performance in environments requiring reduced electromagnetic interference
TEXILine Heli Twist Al:
- DNV-approved 1kV cable with flexible aluminium conductors (IEC 60228 class 5)
- Light weight cost-effective alternative to copper, with comparable performance
- Design for narrow spaces and extreme offshore conditions
TEXILine Heli Twist Al EMC:
- Aluminium variant with braided copper screen for electromagnetic compatibility (EMC)
- Provides robust interference protection in critical installations
TEXILine Heli Twist Cu DC:
- Specially designed for DC installations with flexible copper conductors
- XLPE double insulation supports up to 1.8/3kV for DC ripple or high-voltage requirements
- Helically twisted for optimal heat transfer and current carrying capacity
TEXILine Heli Twist Cu DC EMC:
- DC-specific copper cable with an added copper screen for electromagnetic compatibility (EMC)
- Enhanced electromagnetic protection for sensitive DC systems
TEXILine Heli Twist Al DC:
- Aluminium DC cable with XLPE double insulation, supporting up to 1.8/3kV
- Lightweight and suitable for compact spaces in marine environments
TEXILine Heli Twist AI DC EMC:
- Aluminium DC cable with an added braided copper screen for electromagnetic compatibility (EMC)
- Designed for reliable operation in demanding DC installations
