SteadiShield® from TT Electronics

When engineers need multiple Ethernet screens within a single connector, TT Electronics SteadiShield® offers a compact alternative to conventional braid-and-clamp termination. Its metallised insert provides instant screen termination to a common ground, delivering 360° screening without additional components and helping improve installation repeatability in space-constrained designs. Built on MIL-DTL-5015 and VG95234 style reverse bayonet formats, the connector combines positive locking with multiple keying options for secure mating in rail, military vehicle, telecoms and industrial applications.

SteadiShield® supports five multi-pole contact styles: coax, twinax, triax, quadrax, and 10Gb Ethernet via OcTrain®, giving designers flexibility for mixed high-speed data architectures. With IP67 sealing, RoHS and EN45545-2 compliance, and a 500-mating-cycle rating, the platform is designed to protect signal integrity in braking systems, communication equipment, on-board and trackside cabling, power distribution and driver cabin electronics.  It also comes with alternative plating options, cable assembled versions and interchangeable contacts.

Speak to Aerco about specifying the right SteadiShield® connector for your Ethernet, EMC and harsh-environment requirements.

Download Datasheet here.
